Optics: Our asymmetric lighting distribution is uniquely designed to reduce glare while controlling the overflow of light with the use of indirect LED lighting technology. A 5 mm tempered glass lens is used to protect the LED cavity.
Reflector: The internal indirect reflector has a high reflectivity of 98%. Our V series reflector uses the latest PVD technology.
Efficiency: 3000k – 120 lumens per watt 4000k – 125 lumens per watt 5000k – 130 lumens per watt
Housing: The thin profile, low copper die cast aluminum housing minimizes wind load. Powder coated inside and outside protects the housing from all types of weather.
Mounting: Fixtures comes standard with U-Bracket. Pipe slip fitter and yolk mounts are available upon request and will require MOQ. Custom mounting options can be made according to customer’s specifications, MOQ will apply.
Surge Protection: Built-in 10kV surge protection module is used to prevent fixture damage in the event of an excessive voltage surge, i.e. lightning or transformer malfunction. Optional 20kV surge protection module available upon request.
Warranty: 7 years warranty.
Replacement: 500W LED = 1200W HID /MH / HPS 600W LED = 1500W HID / MH / HPS 800W LED = 2000W HID /MH / HPS
Class I system
Standard input voltage: 100 - 277VAC 50/60 Hz
Optional high voltage: 180 - 528VAC 50/60 Hz
Total harmonic distortion: <20%
Power factor: > 0.9
